BRAND: ProJect Audio

SERIES: DEBUT CARBON DC ESPRIT SB
TYPE: Turntable

The first Debut turntable, introduced in the late 1990s,was a revolution for the hi-fi industry.

For the first time after the arrival of Compact Disc and the assumed demise of vinyl records, an analogue product re-emerged in the “mass market” – something all music lovers could afford.

The new DEBUT CARBON DC ESPRIT SB has been designed to set new standards in this category for the coming decade – perfectly timed as analogue today is again a respected source, while the demand for good turntables with all speeds is growing fast.



OVERVIEW

The CARBON TUBE for the tonearm increases stiffness and decreases unwanted resonance. This material normally is extensively used in high-end tonearms, but – because of cost reasons – was never used in productsat lower price levels. Together with other improvements like an in-crease in platter size and weight to realize even smoother rotation, the overall sound quality is greatly improved.

The approved belt drive design offers low noise AC motor with effective motor decoupling (utilising TPE), ultra precision frequency DC-driven AC generator for ultimate speed stability.Ultimate convenience is achieved, because of electronic speed change („Speed Box“) and the possibility of playing 78rpm.  A simple exchange of stylus to 2M78 (not included) and a drive belt turnover to larger diameter of pulley is required,that´s all.


  • 33/45 & 78rpm out of the box
  • Built-in precision Speed Box with switch on upper side
  • 8,6” carbon tonearm
  • Heavy non resonant acrylic platter
  • New DC power supply with synchronous AC motor
  • New TPE motor suspension
  • Magnetic cartridge 2M red from Ortofon
  • For 78 playback: remove stylus & exchange to 2M78 (not included, retail price around € 80)
  • High-gloss white, red, yellow, green, blue, purple and piano lacquer finish

Share on facebook

Share

TECHNICAL SPECIFICATIONS

Speed
33, 45 / 78 (electronic/manual speed change)

Drive principle
belt drive

Platter
300mm acrylic platter

Mains bearing
stainless steel

Signal to noise
68dB

Tonearm
8,6” Carbon

Effective arm length
218,5 mm



Effective arm mass
6,0 g

Overhang
18,5mm

Tracking force
10 – 30mN

Included accessories
15 volts DC / 1,6A power supply, dust cover

Power connection
110/120 or 230/240 Volt – 50 or 60 Hz

Power consumption
7,4 watt max / < 0,5 watt standby

Dimensions
415 x 118 x 320mm (WxHxD) lid closed

Weight
4,9 kg
