BRAND: MBL

SERIES: 111 F

TYPE: Loudspeakers

Over the last three decades, MBL has played a major part in breathtaking developments in the worldwide audio sector. MBL accompanied and influenced the birth and growth of high-end audio equipment. Throughout the entire process, MBL was driven by its special goal: to be the cutting edge market leader in terms of technology and quality. There was a time when the “Radialstrahler” was only an idea on a sketch-pad. An idea that many people believed would not work, was turned into patent. Thirty years and countless awards later, thousands of audiophiles in the whole world are now closer to their beloved music than they had ever dreamt of.

OVERVIEW

MBL’s goal remains unchanged: developing the most advanced speakers and audio players worldwide plus the establishment of a standard above all competitors – with the highest possible demand on quality. Every single MBL component is man-made, from development and design to the manufacturing, testing and listening – from the idea to the finished product. It’s up to you, the music lover, to assess the result. Your judgement, your emotion when you listen to your favorite piece of music on one of our players, this is what counts at MBL. Let yourself be enchanted by music and the design of our music equipment – all our efforts are dedicated to music and to you.



Share on facebook

Share

TECHNICAL SPECIFICATIONS

System
4-Wege

Frequenzbereich
24 Hz to 40,000Hz

Impedanz
4 Ohm

SPL Schalldruckpegel
83 dB/W/m (2.83V/ 2pi) linear max. 106 dB

Übergangsfrequenzen
170 Hz, 750 Hz, 3500 Hz Linkwitz-Riley, 4th order

Akustische Achse
107 cm

Nennbelastbarkeit
320 W / 550 W



Musikbelastbarkeit
2200 W

Tieftonsystem
2x 220 mm Alu

Bass
Double push-push 2x 150 mm Alu

Mitteltonsystem
Radial MT50, CFK (MBL)

Hochtonsystem
Radial HT37 Al, CFK (MBL)

Maße (BxHxT)
450 x 1130 x 565 mm H (incl. Cover) = 1205 mm

Gewicht
60 kg
