The McIntosh MT-10 marries classic McIntosh glass front panel cosmetics with serious mechanics to create a unique, ready-to-play LP solution. With tracking force, anti-skate and cartridge position preset at the factory the McIntosh MT-10 delivers high performance LP playback with minimal set up.
The turntable base is comprised of a damped sandwich of stainless steel and acrylic plate; a unique combination of dissimilar materials that provides a resonance-free foundation for the tonearm. A massive, 12 pound, 2 ½” thick acrylic platter spins on a cushion of air, elevated by a custom magnetic bearing.
A regulated power supply drives a super-quiet, brushless, Swiss DC motor. Unmatched accuracy is derived from a new electronic speed control that references 1,595 strobe markings per revolution of the platter. Speed adjustments of 331/3, 45, or 78 RPM are made from the front panel and are registered on a blue, backlit McIntosh meter.
A custom tonearm features a rigid, dural-aluminium arm-tube gimbaled in two sapphire (horizontal) and two ceramic (vertical) bearings for the least possible friction. A .5mV moving coil cartridge is included, and features an ebony body with an elliptical stylus.
READY TO PLAY
Tracking force, anti-skate and cartridge position are all preset. The MT-10 is ready to use just moments after unpacking.
MATCHED TONE ARM AND CARTRIDGE
The MT10 tone arm features a specially dampened Dural-Aluminium armtube. The light weight and rigidity of the tone arm is an ideal mate for the custom, medium-weight moving coil cartridge.
The platter is CNC machined from a special silicone acrylic material to a weight of twelve pounds and a thickness of two and one-half inches for near immunity to bass-robbing resonances.
MAGNETIC AIR DAMPED BEARING
The MT10 Turntable Platter rotates on a special magnetic bearing; literally suspended on a cushion of air for near friction-free performance.
MCC10 CARTRIDGE SPECIFICATIONS
0.5 mV at 5 cm/s
Greater than 200 Ohms, 500 Ohms recommended
20Hz to 50,000Hz
6 x 10-6 cm/dyne
RECOMMENDED TRACKING FORCE
Less than 0.3 dB
Ebony wood tone
MT10 TONEARM SPECIFICATIONS
Sapphire and Ceramic
VTA, Antiskate, Azimuth
MT10 TURNTABLE SPECIFICATIONS
PLAYBACK SPEEDS 3
3-1/3 rpm, 45 rpm and 78rpm
electronic w/ braking feature
MT10 EXTERNAL POWER SUPPLY SPECIFICATIONS
24 Volts, 625ma
100 Volts, 50/60Hz at 400ma
110 Volts, 50/60Hz at 400ma
120 Volts, 50/60Hz at 400ma
220 Volts, 50/60Hz at 400ma
230 Volts, 50/60Hz at 400ma
240 Volts, 50/60Hz at 400ma
MT10 TURNTABLE SPECIFICATIONS OVERALL DIMENSIONS
Width is 17-1/2 inches (44.45cm) Height is 8-13/16 inches (22.38cm) Depth is 21 inches (53.34cm) Note: Tone Arm Height will vary depending on type of Cartridge installed.
