BRAND: McIntosh

TYPE: Power Amplifier


  • The versatile MI128 8-Channel Digital Amplifier can be used in many applications ranging from distributed audio to home theater to stereo.
  • Delivers 120 Watts into 8 Ohm speakers or 150 Watts into 4 Ohm speakers via highly sophisticated closed loop digital switching amplifiers that are paired with extremely robust power supplies to produce performance levels that are rarely achieved in distributed audio.
  • Installer-friendly physical dimensions and is 2U rack mountable via the included mounting ears (the ears are removable for non-rack installations).
  • As a highly efficient Class D amplifier, it does not require noisy cooling fans to maintain nominal operating temperature.
  • Multi-color LED indicators display the status of each channel. Features unbalanced inputs plus 2-pole Phoenix style push-in speaker terminals for each channel.
  • Includes volume controls for volume balancing, along with 2 digital audio inputs (either coax or optical) that can be bussed, and channel summing circuits for easy mono signal distribution.
  • Other features included: Loudspeaker Guard signal overload technology that prevents overdriving the speakers; Sentry Monitor™ short-circuit protection that disengages the output stage before current exceeds safe operating levels; BUS input & outputs to easily distribute a stereo signal to multiple outputs and/or multiple amplifiers; individual channel inputs; 12 Volt triggering capabilities; and eco-friendly on/off signal sensing.



Power Output:
120 Watts into 8 Ohm speakers
150 Watts into 4 Ohm speakers

Total Harmonic Distortion:
0.05% maximum from 20Hz to 20kHz

Signal to Noise Ratio:

Dynamic Headroom:
8 Ohms: 2.1dB
4 Ohms: 3.3dB

Damping Factor:
8 Ohms: >65
4 Ohms: >32

Frequency Response:
+0, -0.5dB from 20Hz to 20kHz


8 Unbalanced
2 Digital (coax or optical)

Overall Dimensions (W x H x D):
17-1/2” (44.45cm) 19” (48.3cm with mounting ears)) x 4-5/16” (11cm) x 21” (53.3cm)

22 lbs (10kg) net, 38.4 lbs (17.4kg) in shipping carton
